Filling Electromagnetic Flowmeter

Product parameters

Diameter range: DN2.5~40

Applicable media: water, soft drinks, beer, dairy products, drinks with pulp, tea, coffee, hot drinks, etc

Medium temperature: 140 ° C maximum (when the ambient temperature is less than 40 ° C)

Velocity range: (- 12-12) m/s

Measurement accuracy: ± 0.2% of measured value+1mm/s

Repeatability: 0.08%

Process pressure: DN10~15: maximum 16bar, DN2.5~6/20~40: maximum 40bar

Conductivity: ≥ 5uS/cm (water ≥ 20uS/cm)

Lining material: PFA

Electrode material: 316L, HB, HC, titanium, tantalum, platinum iridium alloy

Protection grade: IP67 standard, IP68 optional

Working power supply: 24VDC ± 25%

Output signal: one pulse output, one RS485 communication

Cleaning temperature: S | P: 150 ° for 1 hour at most, CP: 140 ° for 1 hour at most

Temperature impact: ≤ 3K/s

Shell material: stainless steel 1.4404/1.4408
